The Bit Buffer is a tiny (2” x 1.5”) buffer that uses an ultra-low distortion, low-noise Burr-Brown op amp. Place it at the beginning of your pedal chain to prevent high-frequency loss (tone suck), or right before a long cable to a pedalboard or amp.
The Bit Buffer is always on when power is connected. An internal LED is visible below the power jack.
- Size: 2″ x 1.5″ x 1.2″
- Input impedance: 1 MΩ
- Output impedance: <1 kΩ
- Frequency response (± 3 dB): 20 Hz – 40 kHz
- Signal-to-noise ratio: 90 dB
- Power: 9-18 VDC, center negative
- Current: 20 mA
